4 Inch Stroke Mini Linear Actuator 200lbs Push / Pull Load With Mounting Bracket
Specification of Mini Linear Actuator
| Item name | Mini Linear Actuator |
| Max. stroke | 600MM |
| Max. Static load | 2000N |
| Max. Dynamic load | 1200N |
| Operation Speed | 5mm/s/1200n 7mm/s/1000n |
| Input Signal | 3.3VDC, 5VDC |
| Position Detection | Potentiometer |
| Motor | Brushed DC motor |
| Degree of Protection | IP65 |
| Screw Type | Trapezoidal screw |
| Power Input | 48V/36V/24V/12V |
| Self-locking ability | YES |
| Operating temperature | -35℃~65℃ |
| Optional 1 | Installation size |
Below you can see the correlation between STROKE and LOAD of Mini LINEAR ACTUATOR.
| Stroke Range (mm) | Max Load (Newton) |
| 501-600 | 100 |
| 401-500 | 200 |
| 301-400 | 400 |
| 201-300 | 1000 |
| 30-200 | 1200 |
There are many factors to consider when selecting a linear actuator for an application need.
Some of these important parameters are mentioned below:
- Stroke length (travel length)
- Installation length
- Mounting requirements
- Feedback
- Motor voltage
- Dynamic load
- Static load
- Speed
Lead time of Mini Linear Actuator:
| Quantity(Piece) | 1-10 | 200 | 500 | >1000 |
| Est. Time(days) | 7 | 15-18 | 22 | To be negotiated |
Picture of Mini Linear Actuator
Mini Linear Actuator Bracket:
Applications of Mini Linear Actuators:
Guarantee of Linear Actuator/ Electric Cylinder
Our talented team of designers, engineers and linear actuator assemblers ensure that every linear actuator / electric cylinder that leaves our facility is perfectly suited to saving you time and money. Our linear actuators / electric cylinders can work for a variety of applications.
Interested?
Contact with us now! ^_^
+86 18762658863
